PPTP (Point-to-Point Tunneling Protocol) and Whonix

Introduction[edit]

Question mark Warning: PPTP is fatally flawed and is actively exploited by NSA. [1] If the user cannot find a better option, rely on it for tunneling UDP over Tor but not security. For security use OpenVPN only. See also Combining Tunnels with Tor.

Question mark Warning: This article has not been checked since the latest Whonix release; it may require an update.

In this chapter, PPTP is utilized because it is useful, very easy to configure and well supported by all kind of devices. Compared to a proper set up with a hardware gateway between the internet and the devices you want to torrify it is less secure but doesn't require any kind of hardware or network layout changes.

Virtual Private Networks (VPNs)[edit]

A VPN (Virtual private networkarchive.org) is a method for users to connect to another network and access resources that can be seen from that network.

In this case, VPN is used to allow other users on your local LAN to connect and use your Whonix to connect to Tor with minimal configuration. Unlike Tor-VM where all network connections are forced through Tor or rejected, workstations connected over PPTP are NOT automatically protected against network level leaks and application level exploits.

We use PPTParchive.org here due to its wide install base (every installation of Windows since Windows 95 includes a client) and ease of installation. Be aware of the enormous security issues with PPTParchive.org.

Warning, PPTP should NOT be used with Whonix over the Internet, only for local trusted sources. See below for an OpenVPN implementation that allows use of Tor with minimal client configuration and should be secure enough to allow Internet connections (coming soon).

VPN: Bypassing Censorship and Enabling Free Speech[edit]

Ref: (How to Bypass Internet Censorship @ Flossmanuals.netarchive.org)

Because VPN services tunnelarchive.org all Internet traffic, they can be used for e-mail, instant messaging, Voice over IP (VoIP) and any other Internet service in addition to Web browsing, making everything that travels through the tunnel unreadable to anyone along the way.

If the tunnel ends outside the area where the Internet is being restricted, this can be an effective method of circumvention, since the filtering entity/server sees only encrypted data, and has no way of knowing what data is passing through the tunnel. It has the additional effect of making all your different kinds of traffic look similar to an eavesdropper.

We use VPN here for its “tunnel” capabilities, so that others that you allow access, can take advantage of Tor via Whonix with a single connection.

Install PPTPd[edit]

(Whonix-Gateway)

From your Whonix-Gateway:

apt install pptpd

This will install and start the pptpd daemon on your Whonix-Gateway. Verify its running:

ps aux

Should show something similar to:

root      8357  0.0  0.5  10512   696 ?        Ss   17:26   0:00 /usr/sbin/pptpd

Stop it for the time being, while we configure it.

/etc/init.d/pptpd stop

Configure PPTP[edit]

(Whonix-Gateway)

Configure PPTP settings:

nano /etc/pptpd.conf

Setup your localip and remoteip settings:

localip 192.168.0.1 #your eth1 address
remoteip 192.168.0.200-250 #a range of unassigned IP's

See the official documentation herearchive.org.

Discussion:

This can be potentially confusing, as the documentation in the configuration files are not the best. When you setup a PPTP connection, your Whonix-Gateway will setup a virtual adapter (e.g. ppp0) which will output traffic sent from your client computer (those that connect to your server from your local LAN) to the Whonix-Gateway and allow it to be routed through Tor. So if we want to use this virtual adapter just like a real adapter (e.g. eth0), we need to give it an IP address. That's what the localip option is.

remoteip is a bit simpler. It is the IP address (or addresses) that are assigned to the client's computer when they connect. They get their own virtual adapter, which needs its own IP address.

See the FAQ here for informationarchive.org. For a simple overview of the VPN process see howVPN_works VPNClient @ Ubuntu Community Documentationarchive.org.

localip, for simplicity should be the IP of your eth1, as Tor is already configured to listen here and we don't actually do any routing creating an IP address conflict. remoteip, should be several IP's on your internal network (you should have as many IP's as potential clients, for example the “192.168.0.200-250” range above defines IP's for 50 clients)

(Advanced: localip and remoteip can be set to other networks, other subnets, etc. With our approach it doesn't matter what their IP's are, simply that they exist. It is in fact encouraged that such clients be assigned to a “quarantine” network. Since we don't have routing enabled, other subnets would prevent your client's from seeing each other and your already established “safe” LAN; where your Whonix-Workstation lives. But! The torrc would need to be updated to listen on said addresses as well. Subneting in this fashion is beyond the scope of this document.)

Configure PPTP Options[edit]

(Whonix-Gateway)

nano /etc/ppp/pptpd-options

Verify the following settings are configured as shown:

refuse-pap
refuse-chap
refuse-mschap
require-mschap-v2
require-mppe-128
ms-dns <eth1 address>

Discussion: See official documentation herearchive.org.

refuse-pap: PAP style authenticationarchive.org, insecure, so we don't want to use it if we can help it. refuse-chap: CHAP authenticationarchive.org, insecure. refuse-mschap: MS-CHAParchive.org, insecure require-mschap-v2: MS-CHAPv2archive.org, make sure that any connecting client must use this. It is as secure a we can get for a supported authentication method for PPTP. require-mppe-128: Microsoft Point-to-Point Encryptionarchive.org, as secure encryption as we can get over PPTP, 128 bit is the maximum supported. ms-dns: Use this address as the DNS server for connecting (Windows) clients.

Configure IPtables rules for client connect and disconnect[edit]

(Whonix-Gateway)

The ip-up script is called on each connection by a PPTP client, so we can put special firewall rules here to help with Torifying the traffic through this interface.

nano /etc/ppp/ip-up

Add to the end:

#Firewall rules to add to route PPTP through TOR
#Tor's TransPort
TRANS_PORT#"9040"

iptables -t nat -A PREROUTING -i $PPP_IFACE -p udp --dport 53 -j REDIRECT --to-ports 53
iptables -t nat -A PREROUTING -i $PPP_IFACE -p tcp --syn -j REDIRECT --to-ports $TRANS_PORT

The variable “$PPP_IFACE” is defined in the script (see the documentation at the beginning of the ip-up script) and resolves to the name of the interface established after a PPTP connection (e.g. ppp0).

Similarly the ip-down script is called when tearing down the connection. To prevent your iptables from getting polluted with redundant rules, we remove the previously configured rules here:

nano /etc/ppp/ip-down

Add to the end:

#Firewall rules to add to route PPTP through TOR
#Tor's TransPort
TRANS_PORT#"9040"

iptables -t nat -D PREROUTING -i $PPP_IFACE -p udp --dport 53 -j REDIRECT --to-ports 53
iptables -t nat -D PREROUTING -i $PPP_IFACE -p tcp --syn -j REDIRECT --to-ports $TRANS_PORT


Notice the addition of the -D instead of -A to the rule definitions. This tells iptables to Delete a rule with those parameters rather than Add one.

(See IPTables documentationarchive.org)

Testing[edit]

(Whonix-Gateway)

Start up your PPTP server:

/etc/init.d/pptpd start

(Client)

From a client on your network (preferably one outside of your Tor network, e.g. not your Whonix-Workstation) connect to your VPN server.

Instructions for a variety of clients:

Linux (many flavors, direct from the pptp-client site)archive.org How to configure a connection to a virtual private network (VPN) in Windows XParchive.org VPNClient @ Ubuntu Community Documentationarchive.org Windows 7 VPN step by step guidearchive.org

Now verify the connection on the gateway, after successfully connecting: (Whonix-Gateway)

ifconfig

Should show something like:

ppp0      Link encap:Point-to-Point Protocol
    inet addr:192.168.0.1  P-t-P:192.168.0.200  Mask:255.255.255.255
    UP POINTOPOINT RUNNING NOARP MULTICAST  MTU:1496  Metric:1
    RX packets:91 errors:0 dropped:0 overruns:0 frame:0
    TX packets:71 errors:0 dropped:0 overruns:0 carrier:0
    collisions:0 txqueuelen:3
    RX bytes:10080 (10.0 KB)  TX bytes:3622 (3.6 KB)

.

iptables -vnL -t nat

Should show:

Chain PREROUTING (policy ACCEPT 103 packets, 14589 bytes)
pkts bytes target     prot opt in     out     source                   destination
    0     0 REDIRECT   udp  --  ppp0  *       0.0.0.0/0            0.0.0.0/0 udp dpt:53     redir ports 53
   22  1320 REDIRECT   tcp  --  ppp0  *       0.0.0.0/0            0.0.0.0/0 tcp     flags:0x17/0x02 redir ports 9040

(You may have more information displayed here depending on configuration, but the lines above should at least appear in your PREROUTING chain)

(Client)

On the client you should then be able to connect via Tor.

  • Browse to check.torproject.org and verify the “congratulations” message

Next disconnect from the VPN. On the server you should see several changes: (Whonix-Gateway)

  • ifconfig

should no longer show any ppp interfaces

  • iptables -vnL -t nat

should show no rules that involve any ppp interfaces

You can in fact test several client connections in this way. Each should get a new IP address (192.168.0.201, 192.168.0.202, etc), create a new virtual adapter (ppp1, ppp2, etc) and route through Tor via the Iptables commands (as above).

You can also attempt [LeakTests Leak Testing] to verify that no packets are leaking through your VPN connection.
